Stainless / Nonferrous for Special Wires including Cold Forging, Springs and Profiles

Stainless Wire Dimensions: - 0.02mm – 6.00mm

Material no. According to DIN / DIN EN	Short symbol to DIN EN	Material standard	US standard to AISI
1.4301	X5CrNi 18-10	DIN 17470	AISI 304
1.4303	X4CrNi 18-12	DIN EN 10088-3	AISI 305
1.4306	X2CrNi 19-11	DIN EN 10095	AISI 304 L
1.4310	X10CrNi 18-8		AISI 301/302
1.4401	X5CrNiMo 17-12-2		AISI 316
1.4404	X2CrNiMo 17-12-2		AISI 316 L
1.4435	X2CrNiMo 18-14-3		AISI 316 L
1.4436	X3CrNiMo 17-13-3		AISI 316 L
1.4438	X2CrNiMo 18-15-4		AISI 317 L
1.4439	X2CrNiMoN 17-13-5		-
1.4539	X1NiCrMoCu 25-20-5		AISI 904 L
1.4541	X6CrNiTi 18-10		AISI 321
1.4567	X3CrNiCu 18-9-4		AISI 304 Cu
1.4571	X6CrNiMoTi 17-12-2		AISI 316 Ti
1.4767	X8CrAl 20-5		-
1.4828	X15CrNiSi 20-12		AISI 309
1.4841	X15CrNiSi 25-20		AISI 314
1.4845	X12CrNi 21-25		AISI 310 S
1.4860	X16NiCr 30-20		-
1.4864	X12NiCrSi 36-16		-

Material no. according to DIN / DIN EN	Short symbol to DIN EN	Material standard	US standard to AISI
CW508L	CuZn 37	Brass	C27400
CW507L	CuZn 36	DIN EN 12166	C27000
CW505L	CuZn 30		C26000
CW503L	CuZn 20		C24000
CW502L	CuZn 15		C23000
CW450K	CuSn 4	Bronze	C51100
CW451K	CuSn 5	DIN EN 12166	-
CW452K	CuSn 6		C51900
CW453K	CuSn 8		C52100
2.0065	E-Cu 58	Copper DIN EN 13602	-

Material no. according to DIN / DIN EN	Short symbol to DIN EN	Material standard	US standard to AISI
2.4851	NiCr23Fe	Inconel 601 *	N04400
2.4869	NiCr80-20	Cronix 80

	Flat Wire	Half-Round Wire	Triangular Wire	Square Wire	Glass Cutting Wire
Thickness	0.10mm – 4.00mm	0.20mm – 3.00mm	0.30mm – 3.00mm	0.50mm – 3.50mm	0.60mm x 0.60mm
Width	0.20mm – 6.00mm	0.40mm – 6.00mm	0.50mm – 5.00mm	0.50mm – 3.50mm	0.60mm x 0.60mm
